INCH-POUND
MIL-DTL-16034/11A
13 March 2008
SUPERSEDING
MIL-M-16034/11
2 January 1953
DETAIL SPECIFICATION SHEET
VOLTMETERS, DC, PORTABLE, 0.25-PERCENT ACCURACY CLASS
This specification is mandatory for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-16034.
REQUIREMENTS:
MILLIVOLTS, DC
VOLTS, DC
Single range
Single range
Multiple range
50
3
150
800
300/30
FULL-SCALE
RANGES
100
30
300
200
50
500
500
ITEM
REQUIREMENTS
Scale length
5 inches min
Position influence (balance)
1 percent of scale length, max change
Initial accuracy
0.25 percent max error
Damping factor
5 min
Response time
2 seconds max
Power consumption
30 mA max: millivoltmeters
20 mA max: voltmeters
External-field influence
0.75 percent max change in 5-oersted field
Heat effect at 65 °C
1 percent max change at 65 °C: voltmeters
2 percent max change at 65 °C: millivoltmeters
0.5 percent max permanent change
Temperature influence
0.25 percent max change: voltmeters
0.5 percent max change: millivoltmeters
0.63 percent max change at 0 °C: voltmeters
Low-temperature exposure
1.25 percent max change at 0 °C: millivoltmeters
0.5 percent max permanent change
AMSC N/A
FSC 6625
