MIL-DTL-16034/5A
REQUIREMENTS:
VOLTS, DC
5
50
300
FULL-SCALE
8
80
500
RANGES
15
150
600
30
200
800
ITEM
REQUIREMENTS
Scale length
5 inches min
Position influence (balance)
1 percent of scale length, max change
Initial accuracy
1 percent max error
Damping factor
5 min
Response time
2 seconds max
Power consumption
11 mA. max
External-field influence
1 percent max change in 5-oersted field
Heat effect at 65 °C
2 percent max change at 65 °C
0.5 percent max permanent change
Temperature influence
0.5 percent max change
1.25 percent max change at 0 °C
Low-temperature exposure
0.5 percent max permanent change
Sustained overload
1 percent of scale length, max temporary zero shift
0.5 percent of scale length, max permanent zero shift
0.33 percent max permanent change in indication
Vibration
1 percent max change
Friction effect
2 percent max change
Humidity resistance
2 percent max change
NOTES:
1. Percentages are based on full-scale value unless otherwise indicated herein.
2. Referenced specification shall be of issue in effect on date of invitation for bids.
