MIL-DTL-16034/6A
REQUIREMENTS:
KILOAMPERES,
AMPERES, DC 1/
MILLAMPERES, DC
DC 1/
1
10
100
5
50
300
1
FULL-SCALE
2
20
200
10
80
500
1.5
RANGES
5
50
500
20
100
600
2
30
200
800
3
NOTE:
1/
Ammeters above 50 amperes and all kiloammeters are calibrated for use with 50-millivolt external shunts.
ITEM
REQUIREMENTS
Scale length
5 inches min
Position influence (balance)
1 percent of scale length, max change
Initial accuracy
1 percent max error
Damping factor
5 min
Response time
2 seconds max
Power consumption
500 mV max: milliammeters
150 mV max: self-contained ammeters
50 mV +1 percent, external-shunt type ammeter, (meter with 0.065+0.010-ohm
leads attached)
External-field influence
1 percent max change in 5-oersted field
Heat effect at 65 °C
4 percent max change at 65 °C
0.5 percent max permanent change
Temperature influence
1 percent max change
2.5 percent max change at 0 °C
Low-temperature exposure
0.5 percent max permanent change
Momentary overload
1 percent max change
Sustained overload
1 percent of scale length, max temporary zero shift
0.5 percent of scale length, max permanent zero shift
0.33 percent max permanent change in indication
Vibration
1 percent max change
Friction effect
2 percent max change
Humidity resistance
2 percent max change
NOTES:
1 Percentages are based on full-scale value unless otherwise indicated herein.
2 Referenced specification shall be of the issue in effect on date of invitation for bids.
