MIL-DTL-16034/7A
REQUIREMENTS:
VOLTS, AC
(60, 400, 800 C.P.S.)
FULL-SCALE
150
RANGE
300
600
ITEM
REQUIREMENTS
Scale length
5 inches min
Position influence (balance)
1 percent of scale length, max change
Initial accuracy
1 percent max error
Damping factor
3 min
Response time
2.5 seconds max
Power consumption
10 VA max
Frequency range
60-cycle meters: 25 to 125 cycles, 2 percent max change
Frequency influence
0.5 percent max change for 60-cycle meters
2 percent max change for 400- and 800-cycle meters
External-field influence
3 percent max change in 5-oersted field
Heat effect at 65 °C
3 percent max change at 65 °C
0.5 percent max permanent change
Temperature influence
0.75 percent max change
1.88 percent max change at 0 °C
Low-temperature exposure
0.5 percent max permanent change
Sustained overload
1 percent of scale length, max temporary zero shift
0.5 percent of scale length, max permanent zero shift
0.33 percent max permanent change in indication
Vibration
1 percent max change
Friction effect
2 percent max change
Humidity resistance
2 percent max change
NOTES:
1 Percentages are based on full-scale value unless otherwise indicated herein.
2 Referenced specification shall be of the issue in effect on date of invitation for bids.
