INCH-POUND
MIL-DTL-16034/9A
13 March 2008
SUPERSEDING
MIL-M-16034/9
2 January 1953
DETAIL SPECIFICATION SHEET
VOLTMETERS, AC AND DC, PORTABLE, 0.25-PERCENT ACCURACY CLASS
This specification is mandatory for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-16034.
REQUIREMENTS:
VOLTS: AC AND DC
Single Range
15
150
800
FULL-SCALE RANGES
30
300
60
600
ITEM
REQUIREMENTS
Scale length
5 inches min
Position influence (balance)
1 percent of scale length, max change
Initial accuracy
0.25 percent max error
Direct-current reversal error
0.25 percent max change
Wave-form effect
0.33 percent max change
Damping factor
3 min
Response time
3.4 seconds max
Power consumption
10 VA max: 15-volt range
25 VA max: all meters except 150-volt range
Frequency range
0.5 percent max change at 25 and 125 cycles
Frequency influence
0.2 percent max change at 54 and 66 cycles
External-field influence
0.75 percent max change in 5-oersted field
Heat effect at 65 °C
1 percent max change at 65 °C
0.5 percent max permanent change
Temperature influence
0.25 percent max change
0.63 percent max change at 0 °C
Low-temperature exposure
0.5 percent max permanent change
AMSC N/A
FSC 6625
