MIL-PRF-10304/21G
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Weight: 4 ounces maximum.
Full-scale ranges: See table I.
Scale:
Length: 1 inch minimum.
Pointer deflection: 90° nominal.
Position influence: ±3 percent maximum change for 60° rotation from normal operating position.
Accuracy: ±3 percent.
Overshoot: 50 percent maximum.
Response time: 2 seconds maximum.
Power consumption (loss) (at end scale deflection): 1 mA ±5 percent.
High temperature cycling:
±5 percent.
±3 percent permanent change.
Temperature influence: ±0.75 percent change.
Exposure to extreme temperatures:
±3 percent permanent change.
Overload capacity:
Sustained overload:
±1 percent temporary zero shift.
±1 percent permanent zero shift.
±2 percent permanent change.
Dielectric withstanding voltage: 1,500 volts rms.
TABLE I. Full-scale ranges.
Millivolts
Volts
Zero left
Zero left
Zero center
30
2
30-0-30
50
10
50-0-50
100
20
100-0-100
200
30
300
50
500
100
200
300
2
