INCH-POUND
MIL-DTL-16034/15A
13 March 2008
SUPERSEDING
MIL-M-16034/15
2 January 1953
DETAIL SPECIFICATION SHEET
VOLTMETERS, DC, PORTABLE, 0.5-PERCENT ACCURACY CLASS
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-16034.
REQUIREMENTS:
MILLIVOLTS, DC
VOLTS, DC
Multiple range
Single range
Multiple range
150/15
1
15
300
30/15
1.5
20
500
150/15
FULL-SCALE RANGES
2
30
600
300/30
3
50
750
750/300/7.5
5
100
800
800/300/3
10
150
ITEM
REQUIREMENTS
Scale length
3.2 inches min
Position influence (balance)
1 percent of scale length, max change
Initial accuracy
0.5 percent max error
Damping factor
5 min
Response time
2 seconds max
Power consumption
20 mA max change
Heat effect at 65 °C
2 percent max change at 65 °C: voltmeters
4 percent max change at 65 °C: millivoltmeters
0.5 percent max permanent change
Temperature influence
0.5 percent max change: voltmeters
1 percent max change: millivoltmeters
1.25 percent max change at 0 °C: voltmeters
Low-temperature exposure
2.5 percent max change at 0 °C: millivoltmeters
0.5 percent max permanent change
AMSC N/A
FSC 6625
