MIL-DTL-16034 Meters, Electrical-Indicating \(Switchboard And Portable Types\), General Specification ForThis specification covers switchboard and portable electrical-indicating voltmeters and ammeters, including prefixes, micro, milli, and kilo.

Pages 1 - - 8|||9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26|||


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MIL-DTL-16034B
Test
Requirement
Test
paragraph
paragraph
Visual and mechanical
(see Table V)
inspection (without
opening case)
Position influence
(balance)
Initial accuracy
Dielectric stress
Insulation resistance
Damping factor
Response time
Power consumption
4.5 Test procedures.
4.5.1 Visual and mechanical inspection. Meters shall be inspected to determine compliance with table V.
TABLE V. Visual and mechanical inspection.
Defect
Requirement
Paragraph
classification
Material
3.4 to 3.4.3, inclusive
Major
Design and construction
Minor
Cases
3.6.1 to 3.6.1.3 inclusive
Major
Dial and pointer
Minor
Means of adjustment
Minor
Terminals and connections
Minor
Mounting switchboard meters
3.6.6 to 3.6.6.2, inclusive
Major
Marking
Minor
Workmanship
Major
Window
Major
Scale visibility
Major
17
