MIL-PRF-49192A(CR)
TABLE IV. Level A performance tests.
Description
Requirements
Output frequency
3.1.1
Amplitude modulation
3.1.4
Amplitude modulation - internal
3.1.4
Pulse modulation (PM)
3.1.6
FM deviation
3.1.7
RF voltage output
3.1.8
Output attenuation
3.1.9
Output impedance
3.1.10
Input impedance
3.1.11
NOTE: Level A testing is abbreviated testing (see 6.4.1)
TABLE V. Level B performance tests.
Description
Requirements
Output frequency accuracy
3.1.3
Output frequency response
3.1.3.1
RF spurious output
3.1.3.2
RF noise level
3.1.3.3
External AM sensitivity
3.1.4.1
Percent modulation
3.1.4.2
Modulation distortion
3.1.5.1
FM internal spurious AM
3.1.7.1
Carrier frequency shift
3.1.7.2
Modulation voltage
3.1.7.3
Standing wave ratio (SWR)
3.1.8.1
4.4.2.2 Group D and F tests. Group D electromagnetic interference (EMI) tests and the
Group F Reliability test shall be performed during quality conformance inspection only if not
performed during first article or bid sampling testing.
4.5 Conformance tests.
4.5.1 Open circuit voltage test (see Figure 7 and 8). The open circuit voltage test shall be
measured on equipment in the normal operating configuration. Equipment controls in each
operation mode shall be such that maximum power will be utilized during the open circuit voltage
12
