MIL-PRF-32516
4. VERIFICATION
4.1 Classification of inspections. The inspections specified herein are classified as
specified as follows:
a. First article inspection (see 4.3).
b. Conformance inspection (see 4. 4).
4.2 Inspection conditions. Unless otherwise specified, all inspections shall be
performed in accordance with the test conditions specified in 4.5.
4.3 First article. First article inspections shall be performed on diagnostic units when
required in accordance with Table III testing requirements. The number of first article units shall
be as required in the contract or purchase order (see 6.2.d).
TABLE III. Summary of environmental requirements.
Environmental
Requirement
Test Methods
Conditions/Tests
Temperature, not operating
Temperature, operating
Humidity
Altitude, not operating
Fungus resistance
Random vibration
Bench handling
Electromagnetic Compatibility
(EMC)
4.4 Conformance inspection. The conformance inspections shall include the following
inspection and tests:
4.4.1 Mechanical and visual examination. The equipment shall be given a thorough
mechanical and visual examination, and test to determine that all materials, workmanship, and
safety characteristics comply with the specified requirements.
4.4.2 Electrical circuit configuration. The equipment shall be examined or tested to
confirm that the wiring is correct. Where applicable, the tests shall include the requirements
specified in a and b:
a. All intra-module wiring shall be tested to assure correctness.
b. The module grounding system shall be examined or tested to ensure proper
separation of shield, signal, and framework grounds, and metal-to-metal contact for
panels and components that serve as electromagnetic shields.
8
