MIL-PRF-32516
e. Step 5. Perform the satisfactory operation test.
4.5.11 Electromagnetic compatibility (EMC) (see 3.11.6). The diagnostic equipment
shall be tested in accordance with MIL-STD-461 specific requirements of CE102, CS101,
CS114, CS115, CS116, RE102, and RS103.
4.5.12 Government validation. The emulator is capable of generating multiple
intermittent faults to simulate 256 LRU/WRA conductive paths. The emulator is capable
generating controlled intermittent faults of various durations from 100 nanoseconds to one
second at pseudo random time intervals. The diagnostic equipment must successfully detect all
the intermittent faults (see 3.17).
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as
specified in the contract or order (see 6.2). When packaging of materiel is to be performed by
DoD or in-house contractor personnel, these personnel need to contact the responsible packaging
activity to ascertain packaging requirements. Packaging requirements are maintained by the
Inventory Control Point's packaging activities within the Military Service or Defense Agency, or
within the military service's system commands. Packaging data retrieval is available from the
managing Military Department's or Defense Agency's automated packaging files, CD-ROM
products, or by contacting the responsible packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but
is not mandatory.)
6.1 Intended use. The diagnostic equipment covered by this specification is intended for
use in detecting and isolating intermittent faults in LRU/WRA, chassis and backplanes and their
wire harnesses. The diagnostic equipment is intended to be used with the LRU/WRA (with SRAs
removed) being stimulated by temperature, vibration or vibration/temperature to emulate the
environment in which the fault originally occurred. Appendices A through C provide
recommended guidelines for defining this external stimulation.
6.2 Acquisition requirements. Acquisition documents should specify the following:
a. Title, number, and date of this specification.
b. Title, number, and date of the applicable purchase description.
c. Appropriate category (see 1.2).
d. Number of first article samples (see 4.2).
e. Packaging (see 5.1)
f. If required, the specific issue of documents.
g. First article inspection.
h. Production lot, conformance inspection.
i. The quantity of maintenance and calibration aid sets required will be as specified by
the procuring activity, including: circuit board extenders, special adapters, special
tools, and patch cables.
j. Waivers are required for equipment that incorporates restricted materials (see
3.10.2). The restricted materials are prohibited except where such materials are
15
